Outstanding Drive Performance

Overload capacity up to 150% / 60 sec, and 200% / 3 sec. Suitable for constant torque applications
Supports induction and permanent magnet motors with optional PG cards for highly precise speed and position control
Provides powerful torque output at low frequency (0.5 Hz / 200% without PG vector control; 0 Hz / 200% with PG vector control) for stable heavy-duty operation at low speed and high torque
Built-in constant tension control function
Speed, torque, and position control

Strong System Support

Built-in PLC with 5k steps; Supports system programming to save costs
Built-in STO (SIL2 / PL d) safety function and measures for sudden power outages
All models can be connected through a common DC bus
Built-in Modbus and CANopen interface; optional communication card, including EtherNet/IP, Modbus TCP, EtherCAT, DeviceNet, PROFIBUS DP, and PROFINET
Optional models with built-in ﬁlter
Optional 24V power supply card to reduce unexpected downtime

Flexible Expansion

Built-in two 33 kHz high-speed pulse input terminals (MI6 & 7) and one output terminal (DFM)
Built-in two accessory card slots for PG card, I/O expansion card, communication card, or 24V power card at the same time
Expandable to 3 DI and 3 DO, including 6 ports in total
Expandable to 2 or 3 relays

Advanced Tension Control

Built-in roll diameter calculation by linear speed, material thickness, and distance meter
Two PID parameters: Linearly adjustable to control tension at startup, of small / large rolls, and at high / low linear speed
Tension taper calculation: Automatically adjusts tension per the winding roll diameter to avoid wrinkles or deformation
Friction and inertia compensation for torque control: Automatically compensates friction and inertia during winding / unwinding for constant tension
Automatic roll change by merely using external signal without machine shutdown

Power range
