Part Number	Picture	Size(mm)	Height(mm)	Input Source(Vac)	Power(w)(Max)	Qmax(CMH)	Pmax(Pa)	PFC	Op. Temp	Application
GTW017EUB12		208	122	1P-200~240	240	1177	844	N/A	-25°C~60°C	Precision Cooling / Industrial
GTW025FUC16		208	158	1P-200~277	360	1746	392	Passive	-25°C~60°C	Industrial
GTW040FUC15E-M001		504	154	1P-200~277	420	5350	198	Passive	-25°C~60°C	Industrial / HVAC
GTW040FUC15RS		504	154	1P-200~277	420	5350	179	Passive	-25°C~60°C	Industrial
GTW071PUT23E		810	234	3P-380~480	2700	23134	259	Passive	-25°C~60°C	HVAC
GTW080PUR22E		910	260	3P-380~480	2200	25077	196	Passive	-25°C~60°C	HVAC
GTW080PUU23E		910	260	3P-380~480	3100	30326	265	Passive	-25°C~60°C	HVAC
GTW091PUR22E		1010	237	3P-380~480	2200	30984	155	Passive	-25°C~60°C	HVAC
GTW091PUU23E		1010	237	3P-380~480	3100	36186	219	Passive	-25°C~60°C	HVAC

Part NumberGTW017EUB12


Table-Data

Size(mm)208

Height(mm)122

Input Source(Vac)1P-200~240

Power(w)(Max)240

Qmax(CMH)1177

Pmax(Pa)844

PFCN/A

Op. Temp-25°C~60°C

ApplicationPrecision Cooling / Industrial

Part NumberGTW025FUC16


Table-Data

Size(mm)208

Height(mm)158

Input Source(Vac)1P-200~277

Power(w)(Max)360

Qmax(CMH)1746

Pmax(Pa)392

PFCPassive

Op. Temp-25°C~60°C

ApplicationIndustrial

Part NumberGTW040FUC15E-M001


Table-Data

Size(mm)504

Height(mm)154

Input Source(Vac)1P-200~277

Power(w)(Max)420

Qmax(CMH)5350

Pmax(Pa)198

PFCPassive

Op. Temp-25°C~60°C

ApplicationIndustrial / HVAC

Part NumberGTW040FUC15RS


Table-Data

Size(mm)504

Height(mm)154

Input Source(Vac)1P-200~277

Power(w)(Max)420

Qmax(CMH)5350

Pmax(Pa)179

PFCPassive

Op. Temp-25°C~60°C

ApplicationIndustrial

Part NumberGTW071PUT23E


Table-Data

Size(mm)810

Height(mm)234

Input Source(Vac)3P-380~480

Power(w)(Max)2700

Qmax(CMH)23134

Pmax(Pa)259

PFCPassive

Op. Temp-25°C~60°C

ApplicationHVAC

Part NumberGTW080PUR22E


Table-Data

Size(mm)910

Height(mm)260

Input Source(Vac)3P-380~480

Power(w)(Max)2200

Qmax(CMH)25077

Pmax(Pa)196

PFCPassive

Op. Temp-25°C~60°C

ApplicationHVAC

Part NumberGTW080PUU23E


Table-Data

Size(mm)910

Height(mm)260

Input Source(Vac)3P-380~480

Power(w)(Max)3100

Qmax(CMH)30326

Pmax(Pa)265

PFCPassive

Op. Temp-25°C~60°C

ApplicationHVAC

Part NumberGTW091PUR22E


Table-Data

Size(mm)1010

Height(mm)237

Input Source(Vac)3P-380~480

Power(w)(Max)2200

Qmax(CMH)30984

Pmax(Pa)155

PFCPassive

Op. Temp-25°C~60°C

ApplicationHVAC

Part NumberGTW091PUU23E


Table-Data

Size(mm)1010

Height(mm)237

Input Source(Vac)3P-380~480

Power(w)(Max)3100

Qmax(CMH)36186

Pmax(Pa)219

PFCPassive

Op. Temp-25°C~60°C

ApplicationHVAC
